Jaylor Single Auger mixers are available in a variety of configurations ranging in capacity from 9.9 to 16.3 cubic metres. Ideal for feeding small to mid-sized dairy and cow-calf operations, medium-sized beef feedlots (especially backgrounding and grower operations), as well as large sheep and goat facilities. Each Jaylor is a class leader in quickly processing round or square baled hay and/or baleage into uniform rations that will resist sorting. All Jaylor 5000 Series mixers come standard with Jaylor’s 19mm patented square cut auger.
• Ladder and Platform
• Mixer Level
• Shaker Box
• Square Cut Auger with Sloped Top
• Slide Plate Technology
• Tungsten Carbide Coated Knives
• Welded Mixing Chamber
• Mix Viewing Window
• 2 Restrictor Blades
• Structurally Reinforced Frame
• Rapid Discharge Door
• Galvanized 6’ 41” Discharge Conveyor
• Adjustable Cast Towing Ball Hitch
• Heavy Duty Hubs
• Heavy Duty Single Straight Axle
• 3 Point Weigh System
• Heavy Duty Planetary Gearbox
• Patented Open Loop Oil Reservoir
• Shear Bolt Protection
• Wheel Assembly - Single Straight Axel
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Model | Capacity | Min. HP (PTO) | PTO Speed | Standard Knives per Auger | Standard Extension |
| Jaylor 5350 | 12 cubic metres | 60hp | 540 | 9 | 16" |
| Jaylor 5425 | 15.3 cubic metres | 70hp | 540 | 9 | 16" |
| Jaylor 5575 | 16.3 cubic metres | 80hp | 540 | 11 | 16" |
