Featuring a heavy-duty Hesston-designed and -built reel assembly and flywheel sickle drives plus narrower end shield profiles, it maximises productivity throughout harvest. Other benefits include a fully flexible cutter bar with 8 inches of hydraulic travel and an integrated 12 degrees of hydraulic tilt with a mechanically driven cutter bar and draper belts.
Combined with the variable speed belt, it allows you to manage an even feeding speed to capture as much of your crop as possible, leading to an optimal return on your investment.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
Engine
| Name | 9330 | 9335 | 9340 |
|---|---|---|---|
| Cutting Width ft. (m) | 30 (9.1) | 35 (10.7) | 40 (12.1) |
| Cutter Bar | SCH | SCH | SCH |
| Cutter Bar Float in. (mm) | 8 (203.2) | 8 (203.2) | 8 (203.2) |
| Cutter Bar Drive | Dual mechanical | Dual mechanical | Dual mechanical |
| Variable Speed Side Draper ft./min (m/min) | 384 (117.04) - 602 (183.49) | 384 (117.04) - 602 (183.49) | 384 (117.04) - 602 (183.49) |
| Fixed Speed Side Draper ft./min (m/min) | 557 (169.77) | 557 (169.77) | 557 (169.77) |
